Features:
- Obstruction sensing device reverses motion
- System of coded magnetic limit switches reduces complexity of wiring low-voltage motors; single wire is carried to control panel
- Automatically distinguishes between open limit and closed switches
Technical Features:
| | | |
| Control Unit: | Thalia | | |
| Board Power Supply: | 115 V | Locking: | Mechanical |
| Power Supply: | 24 V | Release: | Triangle Key |
| Power Input: | 40 W | Frequency of Use: | Intensive |
| Useful Rod Stroke: | 18" | Temperature Range: | -4°F to 131°F |
| Max Angle: | 128° | Protective Rating: | IPX4 |
| Cycle Time: | 23 Sec | Battery Back-Up | Optional |
| Type of Limit Switch: | Magnetic |
|
|
